NAS Service

ROLES zfs, samba

The NAS group in the site.yml sets up a machine that uses the "zfs" role for software raid/mirroring and the "samba" role for file sharing to Windows/MacOS clients. Samba is configured on the standard ports. If you are building a new machine or adding disks, be sure to do adequate burn-in testing.

Everyone's use case is different, but my need is a simple fileserver with a shared common area for music and pictures, plus home directories for individual user files.

The zfs role creates zpools and filesystems. We just use the default Debian monthly scrub/trim cron job. I trimmed the zfs role to the basics. Look at this role if you want something that does ZVOLs, custom scrubs, zrepl, and other things. We use the following ansible galaxy modules:

• community.general.zfs
• community.general.zfs_facts
• community.general.zpool_facts

If they are not already present, you can install by doing:

% ansible-galaxy collection install community.general

The samba role installs the samba server and creates local accounts with samba access. You can create whatever shares you want, but we can call out certain ones to be owned by the 'nas-data' user and 'nas-data' group for common areas accessible by all users (media files, family pictures, etc.)

The common role sets up SMART disk monitoring if we set a list of drives to monitor.

Variables

The zfs_pools variable is a list of pools, with a string describing the vdev, along any other settings. It looks something like this.

zfs_pools:
  - name: tank
    vdev: >-
       mirror
       ata-BIGDRIVE1
       ata-BIGDRIVE2
       cache
       nvme-FASTDRIVE

Specify pool properties: for a specific ashift, or filesystem_properties: for things like compression or case sensitivity. The role will create the pools if they do not exist, or force import them if they are available, even if they were not previously exported.

The zfs_filesystems variable lists filesystems, with their properties. The zfs_filesystems_properties_defaults are applied to every filesystem.

zfs_filesystems:
  - name: tank/myfs
    properties:
       mountpoint: /myfs
       casesensitivity: mixed
       quota: 20G

Some settings (casesensitivity, encryption, keyformat, pbkdf2iters, utf8only, and normalization) can only be set at creation time. Use the quota keyword to limit filesystem sizes. The value can use M/G/T units, but when doing so, Ansible will always show the value as changed because zfs reports current the quota in bytes.

For automatic snapshots, configure filesystems in the zfs_snapshot_policy dictionary with templates defined by the zfs_snapshot_templates dictionary. The daily, monthly, weekly, hourly, or frequently (~15min) properties list the number of copies to maintain. Zero indicates no snapshot.

zfs_snapshot_policy:
    tank/myfs: { use_template: base }

zfs_snapshot_templates:
  base:
    frequently: 0
    hourly: 24
    daily: 7
    weekly: 4
    monthly: 6
    yearly: 0
    autosnap: yes
    autoprune: yes

Sanoid runs every 15min from a systemd timer. If this is more frequent than you need, perhaps preventing disks from standby, you can modify it with the zfs_snapshot_timer variable.

Enable SMART monitoring on disks by listing them in the smartd_drives variable. If set, smartmontools is installed and smard.conf is created. It will set up periodic short and long testing with email to the admin address. You can customize the checks by setting smartd_scan_opts, or set smartd_extra_scanlines to put your own freeform lines into the config file.

smartd_drives:
  - /dev/disk/by-id/ata-BIGDRIVE1
  - /dev/disk/by-id/ata-BIGDRIVE2

Set power management and spindown time for your HDDs with the hdparm_drives variable. If set, hdparm is installed and hdparm.conf is created. This variable is a dictionary with the UUID device of the HDD and the parameters to set. Automatic power management (APM) values 1-127 permit spin-down, while 128-254 do not (See "hdparm -B"). Spin down times 1-240 are multiples of 5sec, while 241-251 are 1-11*30min (See "hdparm -S").

hdparm_drives:
    /dev/disk/by-id/ata-BIGDRIVE1:
         apm: 127
         spindown_time: 240
    /dev/disk/by-id/ata-BIGDRIVE2:
         apm: 127
         spindown_time: 240

NAS Samba users are created through the nas_users variable, which takes a list of name, password, and other values. They will have unix accounts with SMB passwords. They will be able to SMB mount shared disks, but unless you add an SSH authorized key, they can only log in on the console.

You can set smbonly if the unix account exists already from some other action and you just want to set the SMB password. The account must already exist at this point if you set to true.

nas_users:
  - name: someuser
    pw: "{{ vault_nas_someuser_pw }}"
    # home: /homenas/someuser   if want homedir elsewhere
    # smbonly: true             skip create unix acct

To change passwords after account creation, log as the user and run smbpasswd. This will change SMB and unix passwords together.

% smbpasswd
Old SMB password: *****
New SMB password: ********
Retype new SMB password: ********
Password changed for user someuser

Managing the System

Use arcstat to get basic status on the memory cache or use the arc_summary command for a more detailed report on the ZFS subsystem.

% arcstat

% arc_summary | more
% arc_summary -d | more

Why These Packages?

The easy path is to buy a commercial NAS and just configure with their web interface. I prefer to assemble my own hardware, but did try TrueNAS. It was very smooth, but assumed total control of the machine. I want a machine that serves files, but can easily be used for general purpose things as well.

Disk sizes have gotten so stupendously huge that I didn't feel comfortable running a straight ext4 filesystem. I've rarely had disk problems, but resilvering a replacement disk on a ZFS mirrored setup is a lot simpler than finding and restoring double digit terabytes from backups.

I chose sanoid over zfs-auto-snapshot because sanoid has a simple configuration file and actually obeys it. I did not want frequent and hourly snapshots but zfs-auto-snapshot seemed to ignore the com.sun:auto-snapshot:frequently and hourly properties, contrary to the documentation.

Samba is an obvious choice if you are going to support Windows clients. NFS is also an obvious choice if any UNIX machines are in the mix. I originally built this for home use, which is mostly Windows with the occasional Linux box, so we'll see if that is sufficient.
